Description
PLCC 2835 Full spectrum Series features High Color Quality with CRI 98 and compact package size which increase the exibility in lamp design and expand the range of applications. With the outperforming efficiency, PLCC 2835 Full spectrum Series is optimized to be used in high-end LED market such as boutique and luxury apparel store.
Description :
· Best luminous and color uniformity
· Enables halogen and CDM replacement
· The article itself presents the actual color
Feature and Benefits :
· High Color Quality with CRI 98
· R1-R15 95 with full color
· Suitable for all SMT assembly methods
· IR reflow process compatible
· Environmental friendly; RoHS compliance
| Order Code | Power(W) | IF(mA) | VF(V) | Typ.Flux(lm) | CRI(Ra) | Color-CCT(K) | Color | LM80 | Typ.IF(mA) | Typ.VF(V) |
| 2T03X8CWA9503001 | 0.5 | 65 | 2.79 | 26 | 95 | 5700 | Cool White | Yes | ||
| 2T03X8NWA9503001 | 0.5 | 65 | 2.79 | 25.8 | 95 | 4000 | Neutral White | Yes | ||
| 2T03X8WWA9503001 | 0.5 | 65 | 2.79 | 25 | 95 | 3000 | Warm White | Yes | ||
| 2T03X5WCATM33001 | 0.5 | 60/chip | 3/chip | 18.7 | 95 | Dual Color (WW+CW) | Yes | |||
| 2T03X5WNATM33001 | 0.5 | 60/chip | 3/chip | 19 | 95 | Dual Color (WW+NW) | Yes | |||
| 2T03X5NCATM33001 | 0.5 | 60/chip | 3/chip | 19.3 | 95 | Dual Color (NW+CW) | Yes | |||
| 2T03X827Z9803001 | 0.2 | 60 | 2.8 | 17.5 | 98 | 2700 | ||||
| 2T03X830Z9803001 | 0.2 | 60 | 2.8 | 18 | 98 | 3000 | ||||
| 2T03X840Z9803001 | 0.2 | 60 | 2.8 | 19 | 98 | 4000 | ||||
| 2T03X527A9803001 | 0.5 | 150 | 2.9 | 51 | 98 | 2700 | ||||
| 2T03X530A9803001 | 0.5 | 150 | 2.9 | 54 | 98 | 3000 | ||||
| 2T03X540A9803001 | 0.5 | 150 | 2.9 | 56 | 98 | 4000 | ||||
| 2T03X530A9809001 | 0.5 | 60 | 8.6 | 60-65 | 98 | 3000 | Warm White | Yes | 60 | 8.66 |
| 2T03X540A9809001 | 0.5 | 60 | 8.6 | 65-70 | 98 | 4000 | Neutral White | Yes | 60 | 8.62 |
| 2T03X557A9809001 | 0.5 | 60 | 8.6 | 70-75 | 98 | 5700 | Cool White | Yes | 60 | 8.59 |
