Your Professional LED Power Supply Manufacturers
Hong Kong Gaina Technology Co., Ltd. was established in 2012 and has been focusing on the LED industry for more than 12 years. Benefit from the huge market of China's LED industry and reliable supplier relations, we have better price advantage, abundant supply and shorter delivery time. Driven by the ethic of ever-improving customer-understanding, Gainer LED aims to provide a fast,consistent, and highly responsive service to global lighting manufacturers and LED distributors.
Why Choose Us
Rigorous Quality Control
Our professional quality control team conducts thorough inspections. Whether it's a full - scale inspection for high - priority orders or a random part - inspection, we leave no stone unturned to guarantee that only the best - quality products reach you.
Our After-Sales
The takes the initiative and constantly strives to update and improve the product range, looking for solutions to the problems and needs raised by our customers.
Our Certificates
Under the strict management of IS09001 quality system, the company's products have passed a series of international standard certificates such as CE, FDA, ROHS, LFGB and so on.
Sales Market
Our customers are widely spread all over the world,such as UK, France, Singapore, Germany , United States, South Korea, Denmark, Argentina, Vietnam etc.
Benefits of LED Power Supply
Precise Current Regulation
Power supplies ensure that LEDs receive a consistent current flow, preventing overcurrent or variations in brightness.
Efficient Power Delivery
By maintaining a steady current, power supplies minimize power wastage and maximize energy efficiency. They minimize voltage drop, so these drivers are great to place in remote locations. This is because they maintain a constant current output, so voltage is automatically increased to compensate for any voltage drop on cables.
Protection for LEDs
Power supplies often incorporate protection mechanisms such as overcurrent protection and short-circuit protection, safeguarding the LEDs from damage.
Types of LED Power Supply
Constant Voltage Power Supplies
These are designed to provide a fixed output voltage, such as 12V or 24V DC. They are typically used with LED strips or other lighting systems where the current is regulated by resistors or built-in drivers.
01
Constant Current Power Supplies
These deliver a consistent current while allowing the voltage to vary as needed. They are ideal for high-power LEDs that require precise current control to avoid overheating or damage.
02
Dimmable Power Supplies
If you want to adjust the brightness of your LEDs, dimmable power supplies are a great option. They work with compatible dimmer switches to provide smooth and reliable dimming capabilities.
03
Waterproof Power Supplies
For outdoor or wet environments, waterproof LED power supplies are essential. They are designed to withstand exposure to moisture, rain, and dust.
04
Smart Power Supplies
With advancements in technology, some LED power supplies now come with smart features like remote control, Wi-Fi connectivity, or compatibility with smart home systems.
05
Technical Data
|
Power: |
150W max. |
|
Input: |
100-240VAC 50/60Hz |
|
Output Voltage: |
12-48V |
|
Output Current: |
100MA-8300MA |
|
Inrush Current: |
65 Amps max. at 230VAC/50Hz,full load |
|
Leakage Current: |
2.5mA Max. at 264VAC input |
|
No Load Power Consumption : |
<0.5W |
|
Protections: |
Short Circuit /Over Current /Over Voltage/over temperature protection |
|
Short Circuit Protection (SCP): |
Protection to Zero Voltage |
|
Over Voltage Protection (OVP): |
≤Vout*150% |
|
Over Current Protection (OCP): |
110%-180% |
|
Working TEMP.: |
-20°C-50°C |
|
Working Humidity: |
5%-90% RH non-condensing |
|
Storage TEMP.,Humidity and altitude: |
-40ºC ~+70°C ambient temperature and a 5% to 95% relative humidity range throughout an altitude range of -60 meters to +5000 meters AMSL. |
Specification of LED Power Supply
|
Model: |
YCL150-0712100 |
YCL150-0413600 |
YCL150-0354200 |
|
DC Voltage: |
2100mA |
3600mA |
4200mA |
|
Rated Current: |
35-71V |
27-41V |
23-35V |
|
Voltage Range: |
150W |
150W |
150W |
|
Rated Power: |
<1% |
<1% |
<1% |
|
Current Ripple & Noise(max.): |
<5% |
<5% |
<5% |
|
Voltage Tolerance: |
±5% |
±5% |
±5% |
|
Line Regulation: |
±3% |
±3% |
±3% |
|
Load Regulation: |
±5% |
±5% |
±5% |
|
Efficiency: |
92% |
92% |
92% |
|
Setup,Rise time: |
1 second max./40 MS max. |
||
Lead Time
|
Quantity (pieces) |
1 - 1000 |
1001 - 5000 |
5001 - 20000 |
> 20000 |
|
Lead time (days) |
15 |
20 |
25 |
To be negotiated |
Packaging & Shipping
FAQ
As one of the leading led power supply manufacturers and suppliers in China, we warmly welcome you to buy cheap led power supply made in China here from our factory. All our products are with high quality and low price.
