Description
Ultra high reliability and luminous efficacy ,PLCC LED Series are optimized to be used as lighting for automotive signal lighting designs or signboard.
Applications :
Automotive Interior/Exterior Lighting
Signal Lighting
Traffic Lighting
Features :
Package: Ag Plated 6 pad design package with silicone resin
Dimension: 3.4 mmx3.3 mm
Chip technology: AlGaInP
View Angle: 120°
Color: λdom =620 nm(Red)
ESD: 2 kV acc. to ANSI/ESDA/JEDEC JS-001 (HBM, Class 2)
MSL: Level 2
Qualifications: The product qualification test based on the guidelines of AEC-Q102
| Order Code | Power(W) | IF(mA) | VF(V) | Typ.Flux(lm) | Typ.Intensity(cd) | CRI(Ra) | Color-CCT(K) | Color | Color-Wavelengthλd(nm) |
| 2T15X5CW70035SA1 | 0.5 | 140 | 3.05 | 50 | 70 | 5700 | Cool White | ||
| 2T15X5PA00035SA1 | 0.5 | 140 | 3.05 | 45 | PC Amber | ||||
| 2T15X5CW70035SAA | 0.5 | 140 | 2.95 | 65 | 70 | 6000 | Cool White | ||
| 2T15X5RX00035SAA | 0.5 | 140 | 2.2 | 9 | Red | 620 | |||
| 2T15X5SR00035SAA | 0.5 | 140 | 2.15 | 5 | Super Red | 630 | |||
| 2T15X5YX00035SAA | 0.5 | 140 | 2.3 | 7 | Yellow | 592 | |||
| 2T15X5RX00035SAB | 0.5 | 140 | 2.1 | 7.2 | Red | 620 | |||
| 2T15X5RX00035WAA | 0.5 | 140 | 2.13 | 9.8 | Red | 620 | |||
| 2T15X5CW70035SA1 | 0.5 | 140 | 2.9 | 60 | 70 | 6000 | Cool White | ||
| 2T15X5PA00035SA1 | 0.5 | 140 | 2.9 | 50 | PC Amber |
