Cree XLamp XP-E2 Amber LED High-Performance XPEBAM-L1-0000-00601 for Signaling and Accents
Procurement Specification Summary:
* Manufacturer: Cree LED (Original XLamp® XP-E2 Series)
* Emitting Color: Saturated Amber (Typical 591nm Dominant Wavelength)
* Luminous Flux: Optimized for high-output performance at 350mA
* Maximum Drive Current: 1000 mA (High-power performance)
* Thermal Path: Ceramic substrate for superior heat management (5 °C/W)
* Form Factor: Industry-standard 3535 Package (3.45 x 3.45 mm)
* Supply Status: Bulk Tape & Reel in stock; Full batch traceability for OEM/EMS.
Description
Product Details
For LED module manufacturers and luminaire designers, the XP-E2 Amber provides a strategic "drop-in" upgrade path. Since it shares the same mechanical footprint and optical center as previous XP generations, fixture manufacturers can immediately boost system brightness and efficiency without the expensive overhead of redesigning secondary optics or PCB layouts.
Critical Engineering Advantages
-- Optimized Thermal Resistance: With a low junction-to-case thermal resistance of 5 °C/W, the XPEBAM series facilitates rapid heat transfer. This stability is vital for maintaining color consistency in high-wattage signaling arrays and preventing the rapid lumen depreciation associated with heat buildup.
-- High Center-Beam Intensity: The compact 3.45 mm x 3.45 mm footprint allows for tight emitter spacing. This high-density capability is essential for designing narrow-beam spotlights and high-visibility traffic indicators with superior "lux-on-target" ratios.
-- Industrial Durability: Backed by extensive LM-80 data, the XP-E2 platform is widely recognized for its resistance to sulfurization and thermal fatigue, making it the preferred source for 50,000+ hour municipal and commercial projects.
| Parameter | Performance Specification |
| Footprint Dimensions | 3.45 mm x 3.45 mm (3535 Package) |
| Dominant Wavelength | 585 nm – 595 nm (Amber Range) |
| Typical Forward Voltage | 2.1 V – 2.5 V |
| Maximum Forward Current | 1000 mA |
| Viewing Angle (FWHM) | 135° |
| Operating Temperature | -40 °C to +100 °C |
| ESD Withstand Voltage | Up to 8 kV (HBM per Mil-Std-883D) |
The XPEBAM-L1-0000-00601 is a staple light source for performance-driven markets:
-- Automotive Signaling: Durable light engine for side markers, turn signals, and emergency vehicle bars requiring high-intensity amber output.
-- Architectural Accent Lighting: Consistent amber wash lighting for facades, bridge coves, and landscape decorative modules where CCT stability is mandatory.
-- Amusement & Gaming hardware: Reliable, high-density amber arrays for entertainment venues and casino hardware where 24/7 operation is required.
Why Source through Gainer LED?
-- Verified Batch Integrity: We guarantee 100% original stock in factory-sealed reels. Every shipment includes full traceability to the manufacturing lot and bin codes.
-- Strategic Wholesale Inventory: We maintain rolling stock of the XP-E2 series to protect our B2B partners and authorized agents from semiconductor lead-time fluctuations.
-- Bin-Specific Consistency: We coordinate wholesale shipments to provide the same chromaticity and flux bins across your entire order, preventing visible tint shift in large installations.
FAQ
Q: Is the XP-E2 Amber compatible with optics designed for white XP-G3 LEDs?
A: Generally, yes. The mechanical dimensions and optical center height are similar. However, because monochromatic LEDs like Amber have different refractive properties, we recommend a brief focal height check to ensure the beam quality meets your specific project needs.
Q: Can I drive the XPEBAM-L1 at 1000mA for a "Turbo" signaling mode?
A: Yes, it is rated for up to 1.0A. However, thermal management is non-negotiable at high currents. To ensure the L70 lifespan, we recommend using a Copper MCPCB with a Direct Thermal Path (DTP) to fully utilize the 5 °C/W thermal path.
Q: Why is 591nm (Dominant Wavelength) the standard for traffic signals?
A: 591nm provides a saturated, high-contrast amber that is universally recognized for safety signaling and complies with international roadway and maritime standards.
Q: Does Gainer LED provide samples for OEM prototyping?
A: Absolutely. We support LED module manufacturers with sample quantities for R&D evaluation and wavelength-matching tests before moving to full-scale wholesale orders.
