Generation 4 Sensus™ LED Series
Pure White Targeted COB Arrays Below the Black Body Locus (BBBL)
Description
Generation 4 Sensus™ LED Series
Features
• Matching the human perception of "Pure white" light
• Designed to provide the look and feel of ceramic metal halide lights
• Wide product range from 1,000lm to over 15,000lm
• 2700K, 3000K and 3500K, 80 and 90CRI standard
• Market specific 3200K, 95CRI Fashion Series
• Highly saturated color rendering version in 2700K, 3000K and 3500K
• 3 SDCM color binning standard, 2 SDCM binning available
• Excellent optical emission uniformitvy and color over angle consistency
• Exceptional long term color stability
• Superior thermal conductivity for uniform heat spreading
• Environmentally friendly: RoHS and REACH compliant
• UL recognized, file # E465703
Applications
• Spotlights/Track Lights
• Downlights
• Shop Lighting
• Hospitality Lighting
• Architectural and Specialty
• Street Lighting
• Parking Lot and Area Lighting
• Tunnel Lighting
CCT, CRI and R9 Values
|
Correlated Color Temperatures |
XX Value |
CRI |
*R9 |
|
2700K, 3000K |
80 |
>80 |
>0 |
|
2700K, 3000K, 3100K, 3500K |
90 |
>90 |
>50 |
|
3200K |
95 |
>95 |
>85 |
Ordering Part Numbers - Sensus
The following tables describe products with typical flux and minimum flux measured attypcal current and specified at Tj = 85ºC. The values at 25ºC are calculated and shown for reference only.
|
Output Flux (lm) |
LES Diamenter (mm) |
Typ . Current (mA) |
Ordering Part Number |
|||
|
Typ. (85ºC) |
Min. (85ºC) |
Calculated Typ. (25ºC) |
3-step MacAdam Ellipse |
2-step MacAdam Ellipse |
||
|
600 |
560 |
640 |
6.3 |
300 |
CXM-6-27-90-18-AC42-F5-3 |
CXM-6-27-90-18-AC42-F5-2 |
|
740 |
690 |
790 |
CXM-6-30-80-18-AC42-F5-3 |
CXM-6-30-80-18-AC42-F5-2 |
||
|
655 |
610 |
700 |
CXM-6-30-90-18-AC42-F5-3 |
CXM-6-30-90-18-AC42-F5-2 |
||
|
655 |
610 |
700 |
CXM-6-31-90-18-AC42-F5-3 |
CXM-6-31-90-18-AC42-F5-2 |
||
|
680 |
630 |
730 |
CXM-6-35-90-18-AC42-F5-3 |
CXM-6-35-90-18-AC42-F5-2 |
||
|
720 |
670 |
775 |
150 |
CXM-6-27-80-36-AC42-F5-3 |
CXM-6-27-80-36-AC42-F5-2 |
|
|
600 |
560 |
640 |
CXM-6-27-90-36-AC42-F5-3 |
CXM-6-27-90-36-AC42-F5-2 |
||
|
740 |
690 |
790 |
CXM-6-30-80-36-AC42-F5-3 |
CXM-6-30-80-36-AC42-F5-2 |
||
|
655 |
610 |
700 |
CXM-6-30-90-36-AC42-F5-3 |
CXM-6-30-90-36-AC42-F5-2 |
||
|
655 |
610 |
700 |
CXM-6-31-90-36-AC42-F5-3 |
CXM-6-31-90-36-AC42-F5-2 |
||
|
680 |
630 |
730 |
CXM-6-35-90-36-AC42-F5-3 |
CXM-6-35-90-36-AC42-F5-2 |
||
|
745 |
695 |
795 |
9.8 |
360 |
CIM-9-27-90-18-AC42-F5-3 |
CIM-9-27-90-18-AC42-F5-2 |
|
915 |
850 |
980 |
CIM-9-30-80-18-AC42-F5-3 |
CIM-9-30-80-18-AC42-F5-2 |
||
|
810 |
755 |
865 |
CIM-9-30-90-18-AC42-F5-3 |
CIM-9-30-90-18-AC42-F5-2 |
||
|
845 |
785 |
905 |
CIM-9-35-90-18-AC42-F5-3 |
CIM-9-35-90-18-AC42-F5-2 |
||
|
745 |
695 |
795 |
180 |
CIM-9-27-90-36-AC42-F5-3 |
CIM-9-27-90-36-AC42-F5-2 |
|
|
915 |
850 |
980 |
CIM-9-30-80-36-AC42-F5-3 |
CIM-9-30-80-36-AC42-F5-2 |
||
|
810 |
755 |
865 |
CIM-9-30-90-36-AC42-F5-3 |
CIM-9-30-90-36-AC42-F5-2 |
||
|
845 |
785 |
905 |
CIM-9-35-90-36-AC42-F5-3 |
CIM-9-35-90-36-AC42-F5-2 |
||
|
1,000 |
930 |
1,070 |
9.8 |
500 |
CLM-9-27-90-18-AC42-F5-3 |
CLM-9-27-90-18-AC42-F5-2 |
|
1,095 |
1,020 |
1,170 |
CLM-9-30-90-18-AC42-F5-3 |
CLM-9-30-90-18-AC42-F5-2 |
||
|
1,095 |
1,020 |
1,170 |
CLM-9-31-90-18-AC42-F5-3 |
CLM-9-31-90-18-AC42-F5-2 |
||
|
1,135 |
1,055 |
1,215 |
CLM-9-35-90-18-AC42-F5-3 |
CLM-9-35-90-18-AC42-F5-2 |
||
|
1,000 |
930 |
1,070 |
250 |
CLM-9-27-90-36-AC42-F5-3 |
CLM-9-27-90-36-AC42-F5-2 |
|
|
1,235 |
1,150 |
1,320 |
CLM-9-30-80-36-AC42-F5-3 |
CLM-9-30-80-36-AC42-F5-2 |
||
|
1,095 |
1,020 |
1,170 |
CLM-9-30-90-36-AC42-F5-3 |
CLM-9-30-90-36-AC42-F5-2 |
||
|
1,095 |
1,020 |
1,170 |
CLM-9-31-90-36-AC42-F5-3 |
CLM-9-31-90-36-AC42-F5-2 |
||
|
1,135 |
1,055 |
1,215 |
CLM-9-35-90-36-AC42-F5-3 |
CLM-9-35-90-36-AC42-F5-2 |
||
Ordering Part Numbers - Sensus
The following tables describe products with typical flux and minimum flux measured attypcal current and specified at Tj = 85ºC. The values at 25ºC are calculated and shown for reference only.
|
Output Flux (lm) |
LES Diamenter (mm) |
Typ . Current (mA) |
Ordering Part Number |
|||
|
Typ. (85ºC) |
Min. (85ºC) |
Calculated Typ. (25ºC) |
3-step MacAdam Ellipse |
2-step MacAdam Ellipse |
||
|
1,000 |
930 |
1,070 |
9.8 |
250 |
CLM-9-27-90-36-AA42-F5-3 |
CLM-9-27-90-36-AA42-F5-2 |
|
1,235 |
1,150 |
1,320 |
CLM-9-30-80-36-AA42-F5-3 |
CLM-9-30-80-36-AA42-F5-2 |
||
|
1,095 |
1,020 |
1,170 |
CLM-9-30-90-36-AA42-F5-3 |
CLM-9-30-90-36-AA42-F5-2 |
||
|
1,135 |
1,055 |
1,215 |
CLM-9-35-90-36-AA42-F5-3 |
CLM-9-35-90-36-AA42-F5-2 |
||
|
1,110 |
1,035 |
1,190 |
CLM-9-40-90-36-AA42-F5-3 |
CLM-9-40-90-36-AA42-F5-2 |
||
|
1,415 |
1,315 |
1,515 |
9.8 |
360 |
CXM-9-27-90-36-AA42-F5-3 |
CXM-9-27-90-36-AA42-F5-2 |
|
1,745 |
1,625 |
1,865 |
CXM-9-30-80-36-AA42-F5-3 |
CXM-9-30-80-36-AA42-F5-2 |
||
|
1,550 |
1,440 |
1,660 |
CXM-9-30-90-36-AA42-F5-3 |
CXM-9-30-90-36-AA42-F5-2 |
||
|
1,610 |
1,495 |
1,725 |
CXM-9-35-90-36-AA42-F5-3 |
CXM-9-35-90-36-AA42-F5-2 |
||
|
1,580 |
1,470 |
1,700 |
CXM-9-40-90-36-AA42-F5-3 |
CXM-9-40-90-36-AA42-F5-2 |
||
|
1,415 |
1,315 |
1,515 |
CXM-9-27-90-36-AC42-F5-3 |
CXM-9-27-90-36-AC42-F5-2 |
||
|
1,745 |
1,625 |
1,865 |
CXM-9-30-80-36-AC42-F5-3 |
CXM-9-30-80-36-AC42-F5-2 |
||
|
1,550 |
1,440 |
1,660 |
CXM-9-30-90-36-AC42-F5-3 |
CXM-9-30-90-36-AC42-F5-2 |
||
|
1,550 |
1,440 |
1,660 |
CXM-9-31-90-36-AC42-F5-3 |
CXM-9-31-90-36-AC42-F5-2 |
||
|
1,835 |
1,705 |
1,960 |
CXM-9-35-80-36-AC42-F5-3 |
CXM-9-35-80-36-AC42-F5-2 |
||
|
1,610 |
1,495 |
1,725 |
CXM-9-35-90-36-AC42-F5-3 |
CXM-9-35-90-36-AC42-F5-2 |
||
|
1,580 |
1,470 |
1,700 |
CXM-9-40-90-36-AC42-F5-3 |
CXM-9-40-90-36-AC42-F5-2 |
||
|
1,825 |
1,695 |
1,955 |
11.6 |
450 |
CXM-11-27-90-36-AA42-F5-3 |
CXM-11-27-90-36-AA42-F5-2 |
|
2,250 |
2,095 |
2,410 |
CXM-11-30-80-36-AA42-F5-3 |
CXM-11-30-80-36-AA42-F5-2 |
||
|
1,995 |
1,855 |
2,135 |
CXM-11-30-90-36-AA42-F5-3 |
CXM-11-30-90-36-AA42-F5-2 |
||
|
2,075 |
1,930 |
2,220 |
CXM-11-35-90-36-AA42-F5-3 |
CXM-11-35-90-36-AA42-F5-2 |
||
|
1,825 |
1,695 |
1,955 |
CXM-11-27-90-36-AC442-F5-3 |
CXM-11-27-90-36-AC442-F5-2 |
||
|
2,250 |
2,095 |
2,410 |
CXM-11-30-80-36-AC442-F5-3 |
CXM-11-30-80-36-AC442-F5-2 |
||
|
1,995 |
1,855 |
2,135 |
CXM-11-30-90-36-AC442-F5-3 |
CXM-11-30-90-36-AC442-F5-2 |
||
|
2,075 |
1,930 |
2,220 |
CXM-11-35-90-36-AC442-F5-3 |
CXM-11-35-90-36-AC442-F5-2 |
||
Ordering Part Numbers - Sensus
The following tables describe products with typical flux and minimum flux measured attypcal current and specified at Tj = 85ºC. The values at 25ºC are calculated and shown for reference only.
|
Output Flux (lm) |
LES Diamenter (mm) |
Typ . Current (mA) |
Ordering Part Number |
|||
|
Typ. (85ºC) |
Min. (85ºC) |
Calculated Typ. (25ºC) |
3-step MacAdam Ellipse |
2-step MacAdam Ellipse |
||
|
1,870 |
1,740 |
2,000 |
14.5 |
450 |
CIM-14-27-90-36-AC42-F5-3 |
CIM-14-27-90-36-AC42-F5-2 |
|
2,305 |
2,145 |
2,465 |
CIM-14-30-80-36-AC42-F5-3 |
CIM-14-30-80-36-AC42-F5-2 |
||
|
2,045 |
1,900 |
2,190 |
CIM-14-30-90-36-AC42-F5-3 |
CIM-14-30-90-36-AC42-F5-2 |
||
|
2,125 |
1,975 |
2,275 |
CIM-14-35-90-36-AC42-F5-3 |
CIM-14-35-90-36-AC42-F5-2 |
||
|
2,075 |
1,930 |
2,220 |
14.5 |
500 |
CLM-14-27-90-36-AA42-F5-3 |
CLM-14-27-90-36-AA42-F5-2 |
|
2,560 |
2,380 |
2,740 |
CLM-14-30-80-36-AA42-F5-3 |
CLM-14-30-80-36-AA42-F5-2 |
||
|
2,270 |
2,110 |
2,430 |
CLM-14-30-90-36-AA42-F5-3 |
CLM-14-30-90-36-AA42-F5-2 |
||
|
2,360 |
2,195 |
2,525 |
CLM-14-35-90-36-AA42-F5-3 |
CLM-14-35-90-36-AA42-F5-2 |
||
|
2,310 |
2,150 |
2,470 |
CLM-14-40-90-36-AA42-F5-3 |
CLM-14-40-90-36-AA42-F5-2 |
||
|
2,075 |
1,930 |
2,220 |
CLM-14-27-90-36-AC42-F5-3 |
CLM-14-27-90-36-AC42-F5-2 |
||
|
2,560 |
2,380 |
2,740 |
CLM-14-30-80-36-AC42-F5-3 |
CLM-14-30-80-36-AC42-F5-2 |
||
|
2,270 |
2,110 |
2,430 |
CLM-14-30-90-36-AC42-F5-3 |
CLM-14-30-90-36-AC42-F5-2 |
||
|
2,270 |
2,110 |
2,430 |
CLM-14-31-90-36-AC42-F5-3 |
CLM-14-31-90-36-AC42-F5-2 |
||
|
2,360 |
2,195 |
2,525 |
CLM-14-35-90-36-AC42-F5-3 |
CLM-14-35-90-36-AC42-F5-2 |
||
|
2,990 |
2,780 |
3,200 |
14.5 |
720 |
CXM-14-27-90-36-AC42-F5-3 |
CXM-14-27-90-36-AC42-F5-2 |
|
3,685 |
3,425 |
3,945 |
CXM-14-30-80-36-AC42-F5-3 |
CXM-14-30-80-36-AC42-F5-2 |
||
|
3,265 |
3,035 |
3,495 |
CXM-14-30-90-36-AC42-F5-3 |
CXM-14-30-90-36-AC42-F5-2 |
||
|
3,265 |
3,035 |
3,495 |
CXM-14-31-90-36-AC42-F5-3 |
CXM-14-31-90-36-AC42-F5-2 |
||
|
3,164 |
2,940 |
3,387 |
CXM-14-32-95-36-AC42-F5-3 |
CXM-14-32-95-36-AC42-F5-2 |
||
|
3,395 |
3,155 |
3,635 |
CXM-14-35-90-36-AC42-F5-3 |
CXM-14-35-90-36-AC42-F5-2 |
||
|
2,990 |
2,780 |
3,200 |
CXM-14-27-90-36-AA42-F5-3 |
CXM-14-27-90-36-AA42-F5-2 |
||
|
3,685 |
3,425 |
3,945 |
CXM-14-30-80-36-AA42-F5-3 |
CXM-14-30-80-36-AA42-F5-2 |
||
|
3,265 |
3,035 |
3,495 |
CXM-14-30-90-36-AA42-F5-3 |
CXM-14-30-90-36-AA42-F5-2 |
||
|
3,395 |
3,155 |
3,635 |
CXM-14-35-90-36-AA42-F5-3 |
CXM-14-35-90-36-AA42-F5-2 |
||
|
3,595 |
3,345 |
3,845 |
14.5 |
900 |
CGM-14-27-90-36-AC42-F5-3 |
CGM-14-27-90-36-AC42-F5-2 |
|
4,435 |
4,125 |
4,745 |
CGM-14-30-80-36-AC42-F5-3 |
CGM-14-30-80-36-AC42-F5-2 |
||
|
3,930 |
3,655 |
4,205 |
CGM-14-30-90-36-AC42-F5-3 |
CGM-14-30-90-36-AC42-F5-2 |
||
|
4,085 |
3,800 |
4,370 |
CGM-14-35-90-36-AC42-F5-3 |
CGM-14-35-90-36-AC42-F5-2 |
||
Ordering Part Numbers - Sensus
The following tables describe products with typical flux and minimum flux measured attypcal current and specified at Tj = 85ºC. The values at 25ºC are calculated and shown for reference only.
|
Output Flux (lm) |
LES Diamenter (mm) |
Typ . Current (mA) |
Ordering Part Number |
|||
|
Typ. (85ºC) |
Min. (85ºC) |
Calculated Typ. (25ºC) |
3-step MacAdam Ellipse |
2-step MacAdam Ellipse |
||
|
3,365 |
3,130 |
3,600 |
17.5 |
800 |
CXM-18-27-90-36-AA42-F5-3 |
CXM-18-27-90-36-AA42-F5-2 |
|
3,680 |
3,420 |
3,940 |
CXM-18-30-90-36-AA42-F5-3 |
CXM-18-30-90-36-AA42-F5-2 |
||
|
3,825 |
3,555 |
4,095 |
CXM-18-35-90-36-AA42-F5-3 |
CXM-18-35-90-36-AA42-F5-2 |
||
|
4,570 |
4,250 |
4,890 |
22.0 |
990 |
CIM-22-30-90-36-AC42-F5-3 |
CIM-22-30-90-36-AC42-F5-2 |
|
4,750 |
4,420 |
5,085 |
CIM-22-35-90-36-AC42-F5-3 |
CIM-22-35-90-36-AC42-F5-2 |
||
|
4,485 |
4,170 |
4,800 |
22.0 |
1050 |
CLM-22-27-90-36-AC42-F5-3 |
CLM-22-27-90-36-AC42-F5-2 |
|
4,905 |
4,560 |
5,250 |
CLM-22-30-90-36-AC42-F5-3 |
CLM-22-30-90-36-AC42-F5-2 |
||
|
4,905 |
4,560 |
5,250 |
CLM-22-31-90-36-AC42-F5-3 |
CLM-22-31-90-36-AC42-F5-2 |
||
|
4,750 |
4,418 |
5,083 |
CLM-22-32-95-36-AC42-F5-3 |
CLM-22-32-95-36-AC42-F5-2 |
||
|
5,095 |
4,740 |
5,450 |
CLM-22-35-90-36-AC42-F5-3 |
CLM-22-35-90-36-AC42-F5-2 |
||
|
7,225 |
6,720 |
7,730 |
22.0 |
1050 |
CXM-22-30-90-54-AC42-F5-3 |
CXM-22-30-90-54-AC42-F5-2 |
|
7,515 |
6,990 |
8,040 |
CXM-22-35-90-54-AC42-F5-3 |
CXM-22-35-90-54-AC42-F5-2 |
||
|
10,705 |
9,955 |
11,455 |
22.0 |
1600 |
CGM-22-30-90-54-AC42-F5-3 |
CGM-22-30-90-54-AC42-F5-2 |
|
11,130 |
10,350 |
11,910 |
CGM-22-35-90-54-AC42-F5-3 |
CGM-22-35-90-54-AC42-F5-2 |
||
|
16,190 |
15,055 |
17,325 |
32.8 |
2400 |
CXM-32-30-90-54-AC42-F5-3 |
CXM-32-30-90-54-AC42-F5-2 |
|
16,830 |
15,650 |
18,010 |
CXM-32-35-90-54-AC42-F5-3 |
CXM-32-35-90-54-AC42-F5-2 |
||
Ordering Part Numbers - Xtreme Sensus
The following tables describe products with typical flux and minimum flux measured attypcal current and specified at Tj = 85ºC. The values at 25ºC are calculated and shown for reference only.
|
Output Flux (lm) |
LES Diamenter (mm) |
Typ . Current (mA) |
Ordering Part Number |
|||
|
Typ. (85ºC) |
Min. (85ºC) |
Calculated Typ. (25ºC) |
3-step MacAdam Ellipse |
2-step MacAdam Ellipse |
||
|
600 |
560 |
640 |
6.3 |
300 |
CXM-6-30-90-18-AC44-F5-3 |
CXM-6-30-90-18-AC44-F5-2 |
|
620 |
575 |
665 |
CXM-6-35-90-18-AC44-F5-3 |
CXM-6-35-90-18-AC44-F5-2 |
||
|
600 |
560 |
640 |
150 |
CXM-6-30-90-36-AC44-F5-3 |
CXM-6-30-90-36-AC44-F5-2 |
|
|
620 |
575 |
665 |
CXM-6-35-90-36-AC44-F5-3 |
CXM-6-35-90-36-AC44-F5-2 |
||
|
745 |
695 |
795 |
9.8 |
180 |
CIM-9-30-90-36-AC44-F5-3 |
CIM-9-30-90-36-AC44-F5-2 |
|
770 |
715 |
825 |
CIM-9-35-90-36-AC44-F5-3 |
CIM-9-35-90-36-AC44-F5-2 |
||
|
745 |
695 |
795 |
360 |
CIM-9-30-90-18-AC44-F5-3 |
CIM-9-30-90-18-AC44-F5-2 |
|
|
770 |
715 |
825 |
CIM-9-35-90-18-AC44-F5-3 |
CIM-9-35-90-18-AC44-F5-2 |
||
|
1,000 |
930 |
1,070 |
9.8 |
250 |
CLM-9-30-90-36-AC44-F5-3 |
CLM-9-30-90-36-AC44-F5-2 |
|
1,035 |
965 |
1,105 |
CLM-9-35-90-36-AC44-F5-3 |
CLM-9-35-90-36-AC44-F5-2 |
||
|
1,420 |
1,320 |
1,520 |
9.8 |
360 |
CXM-9-30-90-36-AA44-F5-3 |
CXM-9-30-90-36-AA44-F5-2 |
|
1,470 |
1,365 |
1,575 |
CXM-9-35-90-36-AA44-F5-3 |
CXM-9-35-90-36-AA44-F5-2 |
||
|
1,420 |
1,320 |
1,520 |
CXM-9-30-90-36-AC44-F5-3 |
CXM-9-30-90-36-AC44-F5-2 |
||
|
1,470 |
1,365 |
1,575 |
CXM-9-35-90-36-AC44-F5-3 |
CXM-9-35-90-36-AC44-F5-2 |
||
|
1,830 |
1,700 |
1,960 |
11.6 |
450 |
CXM-11-30-90-36-AA44-F5-3 |
CXM-11-30-90-36-AA44-F5-2 |
|
1,890 |
1,760 |
2,020 |
CXM-11-35-90-36-AA44-F5-3 |
CXM-11-35-90-36-AA44-F5-2 |
||
|
1,875 |
1,745 |
2,005 |
14.5 |
450 |
CIM-14-30-90-36-AC44-F5-3 |
CIM-14-30-90-36-AC44-F5-2 |
|
1,940 |
1,805 |
2,075 |
CIM-14-35-90-36-AC44-F5-3 |
CIM-14-35-90-36-AC44-F5-2 |
||
|
2,080 |
1,935 |
2,225 |
14.5 |
500 |
CLM-14-30-90-36-AC44-F5-3 |
CLM-14-30-90-36-AC44-F5-2 |
|
2,150 |
2,000 |
2,300 |
CLM-14-35-90-36-AC44-F5-3 |
CLM-14-35-90-36-AC44-F5-2 |
||
|
2,995 |
2,785 |
3,205 |
14.5 |
720 |
CXM-14-30-90-36-AC44-F5-3 |
CXM-14-30-90-36-AC44-F5-2 |
|
3,100 |
2,885 |
3,315 |
CXM-14-35-90-36-AC44-F5-3 |
CXM-14-35-90-36-AC44-F5-2 |
||
|
2,995 |
2,785 |
3,205 |
CXM-14-30-90-36-AA44-F5-3 |
CXM-14-30-90-36-AA44-F5-2 |
||
|
3,100 |
2,885 |
3,315 |
CXM-14-35-90-36-AA44-F5-3 |
CXM-14-35-90-36-AA44-F5-2 |
||
|
3,600 |
3,350 |
3,850 |
14.5 |
900 |
CGM-14-30-90-36-AC44-F5-3 |
CGM-14-30-90-36-AC44-F5-2 |
|
3,725 |
3,465 |
3,985 |
CGM-14-35-90-36-AC44-F5-3 |
CGM-14-35-90-36-AC44-F5-2 |
||
Ordering Part Numbers - Xtreme Sensus
The following tables describe products with typical flux and minimum flux measured attypcal current and specified at Tj = 85ºC. The values at 25ºC are calculated and shown for reference only.
|
Output Flux (lm) |
LES Diamenter (mm) |
Typ . Current (mA) |
Ordering Part Number |
|||
|
Typ. (85ºC) |
Min. (85ºC) |
Calculated Typ. (25ºC) |
3-step MacAdam Ellipse |
2-step MacAdam Ellipse |
||
|
3,375 |
3,140 |
3,610 |
17.5 |
800 |
CXM-18-30-90-36-AA44-F5-3 |
CXM-18-30-90-36-AA44-F5-2 |
|
3,490 |
3,245 |
3,735 |
CXM-18-35-90-36-AA44-F5-3 |
CXM-18-35-90-36-AA44-F5-2 |
||
|
4,190 |
3,895 |
4,485 |
22.0 |
990 |
CIM-22-30-90-36-AC44-F5-3 |
CIM-22-30-90-36-AC44-F5-2 |
|
4,330 |
4,025 |
4,635 |
CIM-22-35-90-36-AC44-F5-3 |
CIM-22-35-90-36-AC44-F5-2 |
||
|
4,495 |
4,180 |
4,810 |
22.0 |
1050 |
CLM-22-30-90-36-AC44-F5-3 |
CLM-22-30-90-36-AC44-F5-2 |
|
4,650 |
4,325 |
4,975 |
CLM-22-35-90-36-AC44-F5-3 |
CLM-22-35-90-36-AC44-F5-2 |
||
|
6,625 |
6,160 |
7,090 |
22.0 |
1050 |
CXM-22-30-90-54-AC44-F5-3 |
CXM-22-30-90-54-AC44-F5-2 |
|
6,850 |
6,370 |
7,330 |
CXM-22-35-90-54-AC44-F5-3 |
CXM-22-35-90-54-AC44-F5-2 |
||
|
9,815 |
9,130 |
10,500 |
22.0 |
1600 |
CGM-22-30-90-54-AC44-F5-3 |
CGM-22-30-90-54-AC44-F5-2 |
|
10,150 |
9,440 |
10,860 |
CGM-22-35-90-54-AC44-F5-3 |
CGM-22-35-90-54-AC44-F5-2 |
||
|
14,840 |
13,800 |
15,880 |
32.8 |
2400 |
CXM-32-30-90-54-AC44-F5-3 |
CXM-32-30-90-54-AC44-F5-2 |
|
15,350 |
14,275 |
16,425 |
CXM-32-35-90-54-AC44-F5-3 |
CXM-32-35-90-54-AC44-F5-2 |
||
CXM-6 Operating Characteristics1
|
Parameter - 36V |
Symbol |
Minimum |
Typical |
Maximum |
Unit |
|
Forward Current2 |
If |
150 |
450 |
mA |
|
|
Forward Voltage3 |
Vf |
31.0 |
33.6 |
37.0 |
V |
|
Parameter - 18V |
Symbol |
Minimum |
Typical |
Maximum |
Unit |
|
Forward Current2 |
If |
300 |
900 |
mA |
|
|
Forward Voltage3 |
Vf |
15.5 |
16.8 |
18.5 |
V |
|
Parameter |
Symbol |
Minimum |
Typical |
Maximum |
Unit |
|
Power |
5.0 |
17.1 |
W |
||
|
Operating Case Temperature |
T c |
120 |
ºC |
||
|
Light Emitting Surface Diameter |
LES |
6.3 |
mm |
||
|
Thermal Resistance (junction-to-case) |
Θjc |
1.0 |
ºC/W |
||
|
Junction Temperature |
Tj |
140 |
ºC |
||
|
Viewing Angle |
120 |
Degree |
CIM-9 Operating Characteristics1
|
Parameter - 36V |
Symbol |
Minimum |
Typical |
Maximum |
Unit |
|
Forward Current2 |
If |
180 |
500 |
mA |
|
|
Forward Voltage3 |
Vf |
31.0 |
33.5 |
37.0 |
V |
|
Parameter - 18V |
Symbol |
Minimum |
Typical |
Maximum |
Unit |
|
Forward Current2 |
If |
360 |
1000 |
mA |
|
|
Forward Voltage3 |
Vf |
15.5 |
16.7 |
18.5 |
V |
|
Parameter |
Symbol |
Minimum |
Typical |
Maximum |
Unit |
|
Power |
6.1 |
19.9 |
W |
||
|
Operating Case Temperature |
T c |
120 |
ºC |
||
|
Light Emitting Surface Diameter |
LES |
9.8 |
mm |
||
|
Thermal Resistance (junction-to-case) |
Θjc |
0.70 |
ºC/W |
||
|
Junction Temperature |
Tj |
140 |
ºC |
||
|
Viewing Angle |
120 |
Degree |
CLM-9 Operating Characteristics1
|
Parameter -36V |
Symbol |
Minimum |
Typical |
Maximum |
Unit |
|
Forward Current2 |
If |
250 |
900 |
mA |
|
|
Forward Voltage3 |
Vf |
31.0 |
33.5 |
37.0 |
V |
|
Parameter -18V |
Symbol |
Minimum |
Typical |
Maximum |
Unit |
|
Forward Current2 |
If |
500 |
1800 |
mA |
|
|
Forward Voltage3 |
Vf |
15.5 |
16.7 |
18.5 |
V |
|
Parameter |
Symbol |
Minimum |
Typical |
Maximum |
Unit |
|
Power |
8.3 |
34.4 |
W |
||
|
Operating Case Temperature |
T c |
120 |
ºC |
||
|
Light Emitting Surface Diameter |
LES |
9.8 |
mm |
CXM-9 Operating Characteristics1
|
Parameter |
Symbol |
Minimum |
Typical |
Maximum |
Unit |
|
Forward Current2 |
If |
360 |
1,100 |
mA |
|
|
Forward Voltage3 |
Vf |
31.0 |
33.5 |
37.0 |
V |
|
Power |
12.1 |
41.9 |
W |
||
|
Operating Case Temperature |
T c |
120 |
ºC |
||
|
Light Emitting Surface Diameter |
LES |
9.8 |
mm |
||
|
Thermal Resistance (junction-to-case) |
Θjc |
0.32 |
ºC/W |
||
|
Junction Temperature |
Tj |
140 |
ºC |
||
|
Viewing Angle |
120 |
Degree |
CXM-11 Operating Characteristics1
|
Parameter |
Symbol |
Minimum |
Typical |
Maximum |
Unit |
|
Forward Current2 |
If |
450 |
1,300 |
mA |
|
|
Forward Voltage3 |
Vf |
31.0 |
33.7 |
37.0 |
V |
|
Power |
15.1 |
49.3 |
W |
||
|
Operating Case Temperature |
T c |
120 |
ºC |
||
|
Light Emitting Surface Diameter |
LES |
11.6 |
mm |
||
|
Thermal Resistance (junction-to-case) |
Θjc |
0.29 |
ºC/W |
||
|
Junction Temperature |
Tj |
140 |
ºC |
||
|
Viewing Angle |
120 |
Degree |
CIM-14 Operating Characteristics1
|
Parameter |
Symbol |
Minimum |
Typical |
Maximum |
Unit |
|
Forward Current2 |
If |
450 |
1,300 |
mA |
|
|
Forward Voltage3 |
Vf |
31.0 |
33.5 |
37.0 |
V |
|
Power |
15.1 |
49.3 |
W |
||
|
Operating Case Temperature |
T c |
120 |
ºC |
||
|
Light Emitting Surface Diameter |
LES |
14.5 |
mm |
||
|
Thermal Resistance (junction-to-case) |
Θjc |
0.28 |
ºC/W |
||
|
Junction Temperature |
Tj |
140 |
ºC |
||
|
Viewing Angle |
120 |
Degree |
CLM-14 Operating Characteristics1
|
Parameter |
Symbol |
Minimum |
Typical |
Maximum |
Unit |
|
Forward Current2 |
If |
500 |
1,800 |
mA |
|
|
Forward Voltage3 |
Vf |
31.0 |
33.5 |
37.0 |
V |
|
Power |
16.6 |
68.7 |
W |
||
|
Operating Case Temperature |
T c |
120 |
ºC |
||
|
Light Emitting Surface Diameter |
LES |
14.5 |
mm |
||
|
Thermal Resistance (junction-to-case) |
Θjc |
0.25 |
ºC/W |
||
|
Junction Temperature |
Tj |
140 |
ºC |
||
|
Viewing Angle |
120 |
Degree |
CXM-14 Operating Characteristics1
|
Parameter |
Symbol |
Minimum |
Typical |
Maximum |
Unit |
|
Forward Current2 |
If |
720 |
2,000 |
mA |
|
|
Forward Voltage3 |
Vf |
31.0 |
33.5 |
37.0 |
V |
|
Power |
24.1 |
75.6 |
W |
||
|
Operating Case Temperature |
T c |
120 |
ºC |
||
|
Light Emitting Surface Diameter |
LES |
14.5 |
mm |
||
|
Thermal Resistance (junction-to-case) |
Θjc |
0.23 |
ºC/W |
||
|
Junction Temperature |
Tj |
140 |
ºC |
||
|
Viewing Angle |
120 |
Degree |
CGM-14 Operating Characteristics1
|
Parameter |
Symbol |
Minimum |
Typical |
Maximum |
Unit |
|
Forward Current2 |
If |
900 |
2,300 |
mA |
|
|
Forward Voltage3 |
Vf |
31.0 |
34.4 |
37.0 |
V |
|
Power |
30.4 |
86.3 |
W |
||
|
Operating Case Temperature |
T c |
120 |
ºC |
||
|
Light Emitting Surface Diameter |
LES |
14.5 |
mm |
||
|
Thermal Resistance (junction-to-case) |
Θjc |
0.22 |
ºC/W |
||
|
Junction Temperature |
Tj |
140 |
ºC |
||
|
Viewing Angle |
120 |
Degree |
CXM-18 Operating Characteristics1
|
Parameter |
Symbol |
Minimum |
Typical |
Maximum |
Unit |
|
Forward Current2 |
If |
800 |
2,500 |
mA |
|
|
Forward Voltage3 |
Vf |
31.0 |
33.5 |
37.0 |
V |
|
Power |
26.8 |
93.8 |
W |
||
|
Operating Case Temperature |
T c |
120 |
ºC |
||
|
Light Emitting Surface Diameter |
LES |
17.5 |
mm |
||
|
Thermal Resistance (junction-to-case) |
Θjc |
0.17 |
ºC/W |
||
|
Junction Temperature |
Tj |
140 |
ºC |
||
|
Viewing Angle |
120 |
Degree |
CIM-22 Operating Characteristics1
|
Parameter |
Symbol |
Minimum |
Typical |
Maximum |
Unit |
|
Forward Current2 |
If |
990 |
3,000 |
mA |
|
|
Forward Voltage3 |
Vf |
31.0 |
33.3 |
37.0 |
V |
|
Power |
33.2 |
112.5 |
W |
||
|
Operating Case Temperature |
T c |
120 |
ºC |
||
|
Light Emitting Surface Diameter |
LES |
22.0 |
mm |
||
|
Thermal Resistance (junction-to-case) |
Θjc |
0.16 |
ºC/W |
||
|
Junction Temperature |
Tj |
140 |
ºC |
||
|
Viewing Angle |
120 |
Degree |
CLM-22 Operating Characteristics1
|
Parameter |
Symbol |
Minimum |
Typical |
Maximum |
Unit |
|
Forward Current2 |
If |
1,050 |
3,500 |
mA |
|
|
Forward Voltage3 |
Vf |
31.0 |
33.5 |
37.0 |
V |
|
Power |
35.2 |
131.3 |
W |
||
|
Operating Case Temperature |
T c |
120 |
ºC |
||
|
Light Emitting Surface Diameter |
LES |
22.0 |
mm |
||
|
Thermal Resistance (junction-to-case) |
Θjc |
0.14 |
ºC/W |
||
|
Junction Temperature |
Tj |
140 |
ºC |
||
|
Viewing Angle |
120 |
Degree |
CXM-22 Operating Characteristics1
|
Parameter |
Symbol |
Minimum |
Typical |
Maximum |
Unit |
|
Forward Current2 |
If |
1,050 |
3,500 |
mA |
|
|
Forward Voltage3 |
Vf |
48.0 |
50.0 |
55.0 |
V |
|
Power |
52.8 |
198.7 |
W |
||
|
Operating Case Temperature |
T c |
120 |
ºC |
||
|
Light Emitting Surface Diameter |
LES |
22.0 |
mm |
||
|
Thermal Resistance (junction-to-case) |
Θjc |
0.12 |
ºC/W |
||
|
Junction Temperature |
Tj |
140 |
ºC |
||
|
Viewing Angle |
120 |
Degree |
CGM-22 Operating Characteristics1
|
Parameter |
Symbol |
Minimum |
Typical |
Maximum |
Unit |
|
Forward Current2 |
If |
1,600 |
4,000 |
mA |
|
|
Forward Voltage3 |
Vf |
48.0 |
50.8 |
55.0 |
V |
|
Power |
81.1 |
225.7 |
W |
||
|
Operating Case Temperature |
T c |
120 |
ºC |
||
|
Light Emitting Surface Diameter |
LES |
22.0 |
mm |
||
|
Thermal Resistance (junction-to-case) |
Θjc |
0.11 |
ºC/W |
||
|
Junction Temperature |
Tj |
140 |
ºC |
||
|
Viewing Angle |
120 |
Degree |
CXM-32 Operating Characteristics1
|
Parameter |
Symbol |
Minimum |
Typical |
Maximum |
Unit |
|
Forward Current2 |
If |
2,400 |
5,000 |
mA |
|
|
Forward Voltage3 |
Vf |
48.0 |
50.8 |
55.0 |
V |
|
Power |
122.9 |
284.8 |
W |
||
|
Operating Case Temperature |
T c |
120 |
ºC |
||
|
Light Emitting Surface Diameter |
LES |
32.8 |
mm |
||
|
Thermal Resistance (junction-to-case) |
Θjc |
0.07 |
ºC/W |
||
|
Junction Temperature |
Tj |
140 |
ºC |
||
|
Viewing Angle |
120 |
Degree |
Hot Tags: generation 4 sensus™ led series, China generation 4 sensus™ led series manufacturers, suppliers, factory, CBT-90-G-C11-JK200, SST-10-R-B90-F630, CBT-140-WCS-L16-TB120, push button switch with led indicator, SST-70X-WCS-H50-JB651, SST-20-WS65-A2-F9652
Send Inquiry
You Might Also Like
