Description
OSLON™ SSL 80 GA CS8PM1.23 New, higher performing OSLON SSL family LED with well known superior robustness, high reliability, long lifetime, low thermal resistance. Perfectly addressing applications demanding for high efficiency and long lifetime requirement.
Features
- Package: SMT ceramic package with silicone lens
- Typ. Radiation: 80°
- ESD: 8 kV acc. to ANSI/ESDA/JEDEC JS-001 (HBM, Class 3B)
- Luminous Flux: typ. 112 lm
- Luminous efficacy: typ. 152 lm/W
|
Type |
Description |
|---|---|
|
Category |
Optoelectronics-LED Color Lighting |
|
Mfr |
ams-OSRAM USA INC. |
|
Series |
OSLON® SSL 80 |
|
Packaging |
Tape & Reel (TR) |
|
Part Status |
Obsolete |
|
Color |
Amber |
|
Wavelength |
617nm (Typ) |
|
Current - Test |
350mA |
|
Voltage - Forward (Vf) (Typ) |
2.1V |
|
Lumens/Watt @ Current - Test |
148 lm/W |
|
Current - Max |
1A |
|
Luminous Flux @ Current/Temperature |
109lm (97lm ~ 121lm) |
|
Temperature - Test |
25°C |
|
Viewing Angle |
80° |
|
Mounting Type |
Surface Mount |
|
Package / Case |
1212 (3030 Metric) |
|
Supplier Device Package |
SMD |
|
Size / Dimension |
0.118" L x 0.118" W (3.00mm x 3.00mm) |
|
Height - Seated (Max) |
0.087" (2.21mm) |
|
Thermal Resistance of Package |
5.3°C/W |
