2T03X827A8003092

2T03X827A8003092

Low power PLCC <0.5W 2835 High efficiency

Send InquiryChat Now
Download

Description

PLCC S Series 2835 UE2.0 features ultra high luminous efficacy and compact package size which increase the flexibility in lamp design and expand the range of applications. With the outperforming efficiency, PLCC S Series 2835 UE2.0 is optimized to be used in high-end LED market such as boutique and luxury apparel store.



Description :

· Best luminous and color uniformity

· Enables halogen and CDM replacement

· The article itself presents the actual color



Feature and Benefits :

· High luminous intensity and high efficiency

· Based on Blue : InGan technology

· Excellent performance and visibility

· Pass LM-80 verification

· Suitable for all SMT assembly methods

· IR reflow process compatible

· Environmental friendly; RoHS compliance



Order Code Power(W) IF(mA) VF(V) Typ.Flux(lm) CRI(Ra) Color-CCT(K) Color Typ(lm/W) LM80
2T03X827A8003092 0.5 65 2.72 34.8 80 2700 Warm white 196.8 Yes
2T03X840A8003092 0.5 65 2.72 39.5 80 4000 Neutral white 223.4 Yes
2T03X857A8003092 0.5 65 2.72 38.1 80 5700 Cool White 215.5 Yes
2T03X527A8003096 0.5 150 2.83 77.5 80 2700 Warm white 182.6 Yes
2T03X540A8003096 0.5 150 2.83 87.1 80 4000 Neutral white 205.2 Yes
2T03X557A8003096 0.5 150 2.83 85.4 80 5700 Cool White 201.2 Yes
2T03X557A8003094 0.5 150 3 80-85 80 5700 Cool White   Yes
2T03X530A8003093 0.5 150 3 70-75 80 3000 Warm White   Yes
2T03X540A8003093 0.5 150 3 75-80 80 4000 Neutral White   Yes
2T03X557A8003093 0.5 150 3 75-80 80 5700 Cool White   Yes
2T03X540A8003094 0.5 150 3 80-85 80 4000 Neutral White   Yes
2T03X530A8003094 0.5 150 3 75-80 80 3000 Warm White   Yes
2T03X557A9003093 0.5 150 3 65-70 90 5700 Cool White   Yes
2T03X540A9003093 0.5 150 3 65-70 90 4000 Neutral White   Yes
2T03X530A9003093 0.5 150 3 60-65 90 3000 Warm White   Yes
2T03X557A9003094 0.5 150 3 70-75 90 5700 Cool White   Yes
2T03X540A9003094 0.5 150 3 70-75 90 4000 Neutral White   Yes
2T03X530A9003094 0.5 150 3 65-70 90 3000 Warm White   Yes
2T03X257A8003093 0.2       80 5700 Cool White   Yes
2T03X240A8003093 0.2       80 4000 Neutral White   Yes
2T03X230A8003093 0.2       80 3000 Warm White   Yes
2T03X257A8003094 0.2       80 5700 Cool White   Yes
2T03X240A8003094 0.2       80 4000 Neutral White   Yes
2T03X230A8003094 0.2       80 3000 Warm White   Yes
2T03X257A9003093 0.2       90 5700 Cool White   Yes
2T03X240A9003093 0.2       90 4000 Neutral White   Yes
2T03X230A9003093 0.2       90 3000 Warm White   Yes
2T03X257A9003094 0.2       90 5700 Cool White   Yes
2T03X240A9003094 0.2       90 4000 Neutral White   Yes
2T03X230A9003094 0.2       90 3000 Warm White   Yes
2T03X857A8003094 0.8       80 5700 Cool White   Yes
2T03X840A8003094 0.8       80 4000 Neutral White   Yes
2T03X830A8003094 0.8       80 3000 Warm White   Yes
