Description
High lumen ,high Color Reproduction Index and luminous efficacy. Due to its slim and miniature size, PLCC LEDs are optimized to be used as lighting for indoor and outdoor application. HS series is high strength type, LED has more robust and more suitable for flexible printed circuit.
Description :
· Best luminous and color uniformity
· Enables halogen and CDM replacement
· The article itself presents the actual color
· High Strength · High Color Reproduction Index
Feature and Benefits :
· High luminous intensity and high efficiency
· Based on Blue : InGan technology
· Wide viewing angle : 120°
· Excellent performance and visibility
· Environmental friendly; RoHS compliance
· IR reflow process compatible
· Suitable for all SMT assembly methods
· More suitable for flexible printed circuit (FPC) application
| Order Code | Power(W) | IF(mA) | VF(V) | Typ.Flux(lm) | CRI(Ra) | Color-CCT(K) | Color | LM80 |
| 2T03X8CWA9503101 | 0.5 | 65 | 2.85 | 28 | 95 | 5700 | Cool White | No |
| 2T03X8NWA9503101 | 0.5 | 65 | 2.85 | 28 | 95 | 4000 | Neutral White | Yes |
| 2T03X8WWA9503101 | 0.5 | 65 | 2.85 | 26 | 95 | 3000 | Warm White | Yes |
| 2T03X250A9003095 | 0.2 | 60 | 3.1 | 24-26 | 90 | 5700 | Cool White | Yes |
| 2T03X230A8003092 | 0.2 | 60 | 3.1 | 22-26 | 80 | 3000 | Warm White | Yes |
| 2T03X240A8003092 | 0.2 | 60 | 3.1 | 24-28 | 80 | 4000 | Neutral White | Yes |
| 2T03X257A8003092 | 0.2 | 60 | 3.1 | 24-28 | 80 | 5700 | Cool White | Yes |
| 2T03X230A9003095 | 0.2 | 60 | 3.1 | 22-24 | 90 | 3000 | Warm White | Yes |
| 2T03X240A9003095 | 0.2 | 60 | 3.1 | 24-26 | 90 | 4000 | Neutral White | Yes |
