Vesta® Series Dim-To-Warm Gen 2 13mm Array
Bridgelux® Vesta® Series Dim-To-Warm Gen 2 13mm Array
Description
Bridgelux® Vesta® Series Dim-To-Warm Gen 2 13mm Array
Bridgelux arrays are fully engineered devices that provide consistent thermal and optical performance on an engineered mechanical platform. The arrays incorporate several features to simplify design integration and assembly.
|
Product Family |
Product |
Part Number |
Doc Number |
LES Size (mm) |
Typ. Flux (lm) |
If (mA) |
Vf (V) |
Power (W) |
Efficacy (lm/W) |
Substrate Size (mm) |
CCT Range (K) |
CRI |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BXRV Vesta DW | Vesta Dim-To-Warm 13A | BXRV-DR-1827G-2000-A-2x | DS192 | 13.5 | 2251 | 600 | 33.5 | 20.1 | 112 | 20x24 | 1800-2700 | 90 |
| BXRV Vesta DW | Vesta Dim-To-Warm 13A | BXRV-DR-1827H-2000-A-2x | DS192 | 13.5 | 1990 | 600 | 33.5 | 20.1 | 99 | 20x24 | 1800-2700 | 95 |
| BXRV Vesta DW | Vesta Dim-To-Warm 13A | BXRV-DR-1830G-2000-A-2x | DS192 | 13.5 | 2432 | 600 | 33.5 | 20.1 | 121 | 20x24 | 1800-3000 | 90 |
| BXRV Vesta DW | Vesta Dim-To-Warm 13A | BXRV-DR-1830H-2000-A-2x | DS192 | 13.5 | 2111 | 600 | 33.5 | 20.1 | 105 | 20x24 | 1800-3000 | 95 |
Table 1: Selection Guide, Measurement Data
|
Part Number |
Nominal CCT 1 Tc=25°C (K) |
Minimum CRI 2 |
Drive Current (mA) |
Typical Vf Tc=25°C (V) |
Typical Power Tc=25°C (W) |
Typical Pulsed Flux 3, 4, 5 Tc=25°C (lm) |
Typical Efficacy Tc=25°C (lm/W) |
Minimum Pulsed Flux 6 Tc=25°C (lm) |
Typical DC Flux 7, 8 Tc=85°C (lm) |
|
BXRV-DR-1827G-2000-A-23 |
2700 |
90 |
600 |
33.5 |
20.1 |
2251 |
112 |
2026 |
2026 |
|
1800 |
90 |
20 |
26.9 |
0.5 |
47 |
88 |
42 |
42 |
|
|
BXRV-DR-1827H-2000-A-23 |
2700 |
95 |
600 |
33.5 |
20.1 |
1990 |
99 |
1791 |
1791 |
|
1800 |
93 |
20 |
26.9 |
0.5 |
39 |
73 |
35 |
35 |
|
|
BXRV-DR-1830G-2000-A-23 |
3000 |
90 |
600 |
33.5 |
20.1 |
2432 |
121 |
2189 |
2189 |
|
1800 |
90 |
20 |
26.9 |
0.5 |
56 |
104 |
50 |
50 |
|
|
BXRV-DR-1830H-2000-A-23 |
3000 |
95 |
600 |
33.5 |
20.1 |
2111 |
105 |
1899 |
1899 |
|
1800 |
93 |
20 |
26.9 |
0.5 |
47 |
87 |
42 |
42 |
Table 2: Table of products registered in the European Product Registry for Energy Labeling (EPREL)
|
|
CCT (K) |
CRI |
Cur- rent 3 (mA) |
Volt- age 3 (V) |
Useful Flux 2 useful Tc=85C (lm) |
Power (W) |
Efficacy (lm/W) |
Energy Efficiency Class 4 |
Regis- tration No |
|
|
|||||||||
|
BXRV-DR-1827G-2000-A-23 |
2700 |
90 |
290 |
30.2 |
1080 |
8.8 |
123 |
E |
879005 |
|
BXRV-DR-1827H-2000-A-23 |
2700 |
95 |
190 |
29.4 |
640 |
5.6 |
114 |
F |
879015 |
|
BXRV-DR-1830G-2000-A-23 |
3000 |
90 |
490 |
31.6 |
1892 |
15.5 |
121 |
E |
879019 |
|
BXRV-DR-1830H-2000-A-23 |
3000 |
95 |
240 |
29.8 |
847 |
7.2 |
118 |
F |
879029 |
Part Number
Table 3: Electrical Characteristics
|
Part Number |
Drive Current (mA) |
Forward Voltage Pulsed, Tc = 25.C 1, 2, 3, 7 |
Typical Coefficient of Forward Voltage ∆Vf/∆Tc (mV/ºC) |
Typical Thermal Resistance Junction to Case 4, 5 (ºC/W) |
Driver Selection Voltages 6 |
|||
|
Minimum (V) |
Typical (V) |
Maximum (V) |
||||||
|
Vf Min. Hot Tc = 105ºC (V) |
Vf Max. Cold Tc = -40ºC (V) |
|||||||
|
BXRV-DR-xxxxx-2000-A-23 |
600 |
31.0 |
33.5 |
36.0 |
-12.1 |
0.23 |
30.0 |
36.8 |
|
720 |
31.5 |
34.0 |
36.6 |
-12.1 |
0.25 |
30.5 |
37.4 |
|
Table 4: Maximum Ratings
|
Parameter |
Maximum Rating |
|
LED Junction Temperature (Tj) |
125°C |
|
Storage Temperature |
-40.C to +105.C |
|
Operating Case Temperature1 (Tc) |
105°C |
|
Soldering Temperature2 |
350°C or lower for a maximum of 10 seconds |
|
Maximum Drive Current3 |
720mA |
|
Maximum Peak Pulsed Drive Current4 |
1030mA |
|
Maximum Reverse Voltage5 |
-60V |
