67-21ST/KK6C-H577696Z6/2T
The Everlight 2835 package has high efficacy, high CRI, low power consumption, wide viewing angle and a compact form factor. These features make this package an ideal LED for all lighting application.
Description
Features
‧ PLCC-2 package
‧ Top view white LED
‧̇High luminous intensity output
‧Wide viewing angle
‧Pb-free
‧ANSI Binning
‧̇The product itself will remain within RoHS compliant version.
‧̇Compliance with EU REACH.
‧Compliance Halogen Free .(Br<900ppm,CI<900ppm,Br+CI<1500ppm)
Description
The Everlight 67-21ST package has high efficacy, high CRI, low power consumption, wide viewing angle and a compact form factor. These features make this package an ideal LED for all lighting applications.
Applications
‧ General lighting
‧ Decorative and Entertainment Lighting
‧ Indicators
‧ Illumination
| Product | Luminous Efficacy(lm/W) | CRI(Min.) | Luminous Flux (Typ.) | Luminous Flux (Min.) | CCT(K) | Forward Current (mA) | Forward Voltage (V) | Power(W) | Dimension (mm) | Series |
| 67-21ST/KK6C-H277096Z6/2T | 133 | 80 | 74 | 70 | 2700K | 60 | 8.7~9.6 | 0.5W | 2.8*3.5*0.7 | 0.5w-9v Series |
| 67-21ST/KK6C-H307396Z6/2T | 138 | 80 | 77 | 73 | 3000K | 60 | 8.7~9.6 | 0.5W | 2.8*3.5*0.7 | 0.5w-9v Series |
| 67-21ST/KK6C-H407696Z6/2T | 143 | 80 | 80 | 76 | 4000K | 60 | 8.7~9.6 | 0.5W | 2.8*3.5*0.7 | 0.5w-9v Series |
| 67-21ST/KK6C-H507696Z6/2T | 143 | 80 | 80 | 76 | 5000K | 60 | 8.7~9.6 | 0.5W | 2.8*3.5*0.7 | 0.5w-9v Series |
| 67-21ST/KK6C-H577696Z6/2T | 143 | 80 | 80 | 76 | 5700K | 60 | 8.7~9.6 | 0.5W | 2.8*3.5*0.7 | 0.5w-9v Series |
| 67-21ST/KK6C-H657696Z6/2T | 143 | 80 | 80 | 76 | 6500K | 60 | 8.7~9.6 | 0.5W | 2.8*3.5*0.7 | 0.5w-9v Series |
