MP-3030-11F2 Mid Power LED

Features
• High efficacy
• CRI Options: Minimum 70, 80, 90
• Low thermal resistance
• Compatible with automatic placement equipment
• Compatible with infrared reflow solder process
• Sulfur resistant

Applications
• Replacement lamps
• Panel lighting
• Down lights
• Horticulture

Ordering Part Numbers

Minimum CRI1	Nominal CCT	Luminous Flux2		Ordering Part Number
Minimum CRI1	Nominal CCT	Minimum Flux (lm)3	Typical Flux (lm)3	Ordering Part Number
70	2700K	36.0	38.0	MP-3030-11F2-27-70
80		34.0	35.5	MP-3030-11F2-27-80
90		30.0	31.0	MP-3030-11F2-27-90
70	3000K	36.0	39.0	MP-3030-11F2-30-70
80		36.0	37.0	MP-3030-11F2-30-80
90		30.0	32.0	MP-3030-11F2-30-90
70	3500K	38.0	41.0	MP-3030-11F2-35-70
80		36.0	38.5	MP-3030-11F2-35-80
90		32.0	33.5	MP-3030-11F2-35-90
70	4000K	38.0	41.0	MP-3030-11F2-40-70
80		38.0	40.0	MP-3030-11F2-40-80
90		33.0	35.0	MP-3030-11F2-40-90
70	5000K	38.0	41.0	MP-3030-11F2-50-70
80		38.0	40.0	MP-3030-11F2-50-80
90		33.0	35.0	MP-3030-11F2-50-90
70	5700K	38.0	41.0	MP-3030-11F2-57-70
80		37.5	39.5	MP-3030-11F2-57-80
90		32.5	34.5	MP-3030-11F2-57-90
70	6500K	38.0	41.0	MP-3030-11F2-65-70
80		37.5	39.5	MP-3030-11F2-65-80
90		32.5	34.5	MP-3030-11F2-65-90

PPF and PPF/W Performance1

PPF (μmol/s)	PPF/W (μmol/J)	Ordering Part Number
0.53	3.01	MP-3030-11F2-27-80
0.56	3.18	MP-3030-11F2-30-80
0.58	3.36	MP-3030-11F2-35-80
0.60	3.40	MP-3030-11F2-40-80
0.58	3.31	MP-3030-11F2-50-80
0.57	3.26	MP-3030-11F2-57-80
0.55	3.18	MP-3030-11F2-65-80

Binning Structure

All MP-3030-11F2 monochromatic LEDs are tested for luminous flux/ dominant wavelength and placed into one of the following flux/wavelength bins. The binning structure is universally applied across each monochromatic color of the MP-3030-11F2 product line.

Flux Bins

Bin Code	Binning @ 65 mA, Tc= 25°C1
Bin Code	Minimum Flux (lm)	Maximum Flux (lm)
D7	28.0	30.0
D8	30.0	32.0
D9	32.0	34.0
E1	34.0	36.0
E2	36.0	38.0
E3	38.0	40.0
E4	40.0	42.0

Forward Voltage Bins2

Bin Code	Binning @ 65 mA, Tc= 25°C1
Bin Code	Minimum Voltage (V)	Maximum Voltage (V)
Y1	2.5	2.6
Z1	2.6	2.7
A1	2.7	2.8

Binning Structure

Color Bins1

Color Code	Center		Radius		Angle(°)
Color Code	x	y	a	b	.
22M3	0.5065	0.4171	0.007500	0.004200	53.00
22M5	0.5065	0.4171	0.012500	0.007000	53.00
27M3	0.4582	0.4099	0.008100	0.004200	53.42
27M5	0.4582	0.4099	0.013500	0.007000	53.42
30M3	0.4342	0.4028	0.008340	0.004080	53.13
30M5	0.4342	0.4028	0.013900	0.006800	53.13
35M3	0.4080	0.3916	0.009270	0.004140	54.00
35M5	0.4080	0.3916	0.015450	0.006900	54.00
40M3	0.3825	0.3798	0.009390	0.004020	53.43
40M5	0.3825	0.3798	0.015650	0.006700	53.43
50M3	0.3451	0.3554	0.008220	0.003540	59.37
50M5	0.3451	0.3554	0.013700	0.005900	59.37
57M3	0.3290	0.3417	0.006705	0.003300	58.35
57M5	0.3290	0.3417	0.011175	0.005500	58.35
65M3	0.3130	0.3290	0.006690	0.002850	58.34
65M5	0.3130	0.3290	0.011150	0.004750	58.34

Absolute Maximum Ratings1,2,3

Parameter		Symbol	Values	Unit
Forward Current	Maximum	If max	400	mA
Pulse Forward Current	Maximum	Ifp max	600	mA
Power Dissipation		Pd	1100	mW
Reverse Voltage		V r	5	V
Operating Temperature Range		T opr	-40 to 85	°C
Storage Temperature Range		T stg	-40 to 85	°C
Junction Temperature		T j	125	°C

Characteristics

Parameter (If=65 mA, Tc=25°C)		Symbol	Value	Unit
Forward Voltage	Minimum	Vf min	2.55	V
	Typical	Vf typ	2.65
	Maximum	Vf max	2.75
Reverse Current (Vr=5 V)	Maximum	I r max	10	µA
Viewing Angle		2θ1/2	120	°
Thermal Resistance		Rth J-C	10	.C/W
Electrostatic Discharge		VESD	8000	V
