GW CSSRM1.BM-MQMS-XX57-1

ΦV = 194 ... 240 lm, 3000 K (IF = 700 mA)

Description

OSLON® Square GW CSSRM1.BM Higher performance. Lower thermal resistance. Extended range of driving conditions. This is the second generation OS- LON Square.

Applications
- Entertainment
- Indoor Lighting
- Medical Lighting
- Outdoor & Industrial Lighting

Features
- Package: SMT ceramic package with silicone lens
- Typ. Radiation: 120° (Lambertian emitter)
- Color temperature: 2700K - 4000K
- CRI: 95 (min.), 97 (typ.)
- Lumen maintenance: Test results according to IESNA LM-80 available
- ESD: 8 kV acc. to ANSI/ESDA/JEDEC JS-001 (HBM, Class 3B)
- Luminous Flux: typ. 192 lm @ 3000 K, 85 °C
- Luminous efficacy: typ. 98 lm/W @ 3000 K, 85 °C

Product Attribute	Attribute Value
Manufacturer:	ams OSRAM
Product Category:	White LEDs
RoHS:
Wavelength/Color Temperature:	3000 K
Series:	GW CSSRM1.BM
Packaging:	Reel
Brand:	ams OSRAM
Moisture Sensitive:	Yes
	600
Subcategory:	LEDs
Tradename:	OSLON
Part # Aliases:	Q65113A9538
