Description
Description
- Small size suitable for compact appliances
- Surface-mounted chip LED device.
- Pb-free and RoHS complaintcomponent.
- High brightness, High efficiency
- Tape and Reel packing.
- Increases the life time of battery.
Features
- 1.6 x0.8 x0.8 mm
- Untinted, Diffused flat mold
- Peak Wavelength :660nm
Applications
- Cellular phone's keypad lightning
- Information Boards
| Part No. | Color | Wavelength [nm] |
Size LxWxH[mm] |
TyP[V] | If[mA] | Luminous intensity Typ[cd] |
View Angle[deg.] |
| SCAA106A-FB102 | AMBER | 590 | 1.6x0.8x0.6 | 2.1 | 20 | 100 | 140 |
| SCB0104A-NB104 | Blue | 470 | 1.6x0.8x0.4 | 3 | 5 | 45 | 140 |
| SCB0104Z-NB104-Z | Blue | 470 | 1.6x0.8x0.4 | 3 | 5 | 30 | 140 |
| SCG0104A-TG104 | Green | 525 | 1.6x0.8x0.4 | 3.2 | 20 | 240 | 140 |
| SCRH108A-UR101 | Red | 660 | 1.6x0.8x0.8 | 1.9 | 20 | 85 | 156 |
