RF-A3E27-W60E-B1
- Vertical table paste package, excellent anti-vulcanization performance; - Package size 2.7*2.0*0.55mm; - AEC -- Q102 certification
Description
1.1General Description
The White LED, which was fabricated by using a blue chip and the phosphor.
Product Package:2.7mmX2.0mmX0.6mm.
1.2Features
► EMC Package.
►Extremely wide viewing angle.
►Available on tape and reel.
►Suitable for all SMT assembly and solder process.
►Moisture sensitivity level: Level 2.
►RoHS compliant.
►Qualifications: The product qualification test plan is based on the guidelines of AEC-Q102 Stress Test Qualification for Automotive Grade Discrete Semiconductors
1.3Application
► Automotive Lighting Interior and Exterior.
|
Product |
Power |
Color |
Ta @25℃(TYP.) |
Max current (mA) |
viewing angle (°) |
ESD withstand voltage()HBM |
automotie standard |
|||
|
IF(mA) |
vf(V) |
Flux/Iv |
XY/Wd |
|||||||
|
RF-A3E27-W60E-B1 |
0.5W |
White |
150 |
2.8-3.4 |
55.3-61.2-67.8-75.3-83.7 |
VM1/VM2/VM3/VM4/VM5/VM6/VM7 |
240 |
120° |
8000 |
AEC-Q102 |
|
RF-A3E27-W60H-B3 |
1.0W |
White |
350 |
2.8-3.4 |
105-117-130-144 |
VM1/VM2/VM3/VM4/VM5/VM6/VM7 |
420 |
120° |
8000 |
AEC-Q102 |
|
RF-A3E27-WYSE-B1 |
0.5W |
PC Amber |
150 |
2.8-3.4 |
40.9-45.3-50-55.3-61.2 |
AM1 (0.572,0417) |
240 |
120° |
8000 |
AEC-Q102 |
|
RF-A3E27-WYSG-B3 |
1.0W |
PC Amber |
300 |
2.8-3.4 |
67.8-75.3-83.7-93.2 |
AM1 (0.572,0417) |
360 |
120° |
8000 |
AEC-Q102 |
|
RF-A4E27-R15E-R4 |
0.5W |
Red |
150 |
2.0-2.6 |
26.9-30-33.4-37 |
612.5-615-617.5-620 |
200 |
120° |
8000 |
AEC-Q102 |
|
RF-A4E27-R22E-R4 |
0.5W |
Red |
150 |
2.0-2.6 |
24.2-26.9-30-33.4-37 |
617.5-620-622.5-625 |
200 |
120° |
8000 |
AEC-Q102 |
|
RF-A4E27-R30E-R4 |
0.5W |
Red |
150 |
2.0-2.6 |
16-17.7-19.6-24.2 |
627.5-630-632.5-635 |
200 |
120° |
8000 |
AEC-Q102 |
|
RF-A4E27-R15H-S4 |
1.0W |
Red |
350 |
2.0-2.6 |
55.3-61.2-67.8-75.3 |
612.5-615-617.5-620 |
420 |
120° |
8000 |
AEC-Q102 |
|
RF-A4E27-R15H-S6 |
1.0W |
Red |
350 |
2.0-2.6 |
61.2-67.8-75.3-83.7 |
612.5-615-617.5-620 |
420 |
120° |
8000 |
AEC-Q102 |
|
RF-A4E27-R22H-S1 |
1.0W |
Red |
350 |
2.0-2.6 |
50-55.3-61.2-67.8 |
617.5-620-622.5-625 |
420 |
120° |
8000 |
AEC-Q102 |
|
RF-A4E27-R30H-S4 |
1.0W |
Red |
350 |
2.0-2.6 |
40.9-45.3-50-55.3 |
627.5-630-632.5-635 |
420 |
120° |
8000 |
AEC-Q102 |
|
RF-A4E27-R15M-S6 |
2.0W |
Red |
700 |
2.2-2.8 |
93.2-105-117 |
612.5-615-617.5-620 |
840 |
120° |
2000 |
AEC-Q102 |
|
RF-A4E27-R22M-S2 |
2.0W |
Red |
700 |
2.2-2.8 |
83.7-93.2-105-117 |
617.5-620-622.5-625 |
700 |
120° |
2000 |
AEC-Q102 |
|
RF-A4E27-Y92E-Y4 |
0.5W |
Yellow |
150 |
2.0-2.6 |
19.6-21.8-24.2-26.9 |
587.5-590-592.5-595 |
180 |
120° |
2000 |
AEC-Q102 |
|
RF-A4E27-Y92H-S4 |
1.0W |
Yellow |
350 |
2.0-2.6 |
40.9-45.3-50-55.3 |
587.5-590-592.5-595 |
420 |
120° |
2000 |
AEC-Q102 |
