SST-10-R Red LED

Features
• High Power Red LED with Peak Wavelength of 630 nm
• Wall-Plug Efficiency: typ. 49% @350 mA
• 80° or 120° viewing angle at 50% Iv
• Low Thermal Resistance
• 6 kV HBM ESD rating per ANSI/ESDA/JEDEC JS-001

Applications
• Horticulture / Growlights
• Architectural lighting
• Accent and effect lighting
• Stage lighting

Ordering Part Numbers1

Color	Radiometric Flux		Wavelength Bins	Ordering Part Number
	Minimum Flux Bin1	Minimum Flux²
Red	G	270 mW	615, 620, 625	SST-10-R-B90-G630
				SST-10-R-B130-G630
	H	310 mW	615, 620, 625	SST-10-R-B90-H630
				SST-10-R-B130-H630
	J	350 mW	615, 620, 625	SST-10-R-B90-J630
				SST-10-R-B130-J630

Part Number Nomenclature

SST 10 R <B###> <ffwww>

Product Family

Chip Area

Color

Package Configuration

Bin Kit

S: Surface Mount

S: Dome Lensed

T: Single Emitter

10: 1.0 mm2

R: Red

<B> Solder Pad Configuration

B: type B - see page 9 <#> Viewing Angle

90: 80°

130: 120°

<ff> Minimum Flux Bin, see 'Binning structure' on page 3 for details

<www> Wavelength Bin

Kit, see 'Binning structure' on page 3 for details

Binning Structure

Luminous Radiometric Flux Bins1

Flux Bin	Binning @ 350 mA, Tc=25°C
Flux Bin	Minimum Flux (mW)	Maximum Flux (mW)
G	270	310
H	310	350
J	350	390
K	390	430

Forward Voltage Bins2

Voltage Bin	Binning @ 350 mA, Tc= 25°C
Voltage Bin	Minimum Voltage (V)	Maximum Voltage (V)
V1	1.8	2.6

Dominant Wavelength Bins2

Wavelength Bin	Binning @ 350 mA, Tc= 25°C
Wavelength Bin	Minimum Wavelength (nm)	Maximum Wavelength (nm)
615	615	620
620	620	625
625	625	630

Radiometric Power to Lumens Conversion2

Radiometric Power to Lumens			Dominant Wavelength (nm)
Radiometric Power to Lumens			615 nm	620 nm	625 nm	630 nm
Flux Bin	G	270 mW	66 lm	53 lm	41 lm	31 lm
	H	310 mW	76 lm	60 lm	47 lm	35 lm
	J	350 mW	86 lm	68 lm	53 lm	40 lm
	K	390 mW	96 lm	76 lm	59 lm	44 lm

Characteristics

Parameter (If=350 mA, Tc=25°C)		Symbol	Value	Unit
Forward Voltage	Minimum	Vf min	1.8	V
	Typical	Vf typ	2.1
	Maximum	Vf max	2.6
Forward Current		If	350	mA
Output Power		Φr	360	mW
Wall-Plug Efficiency		WPE	49	%
FWHM	Minimum	1/2 min	16	nm
	Typical	Δλ 1/2 typ	20
	Maximum	1/2 max	24
Viewing Angle		2θ1/2	80 or 120	°
Dominant Wavelength	Minimum	λd min	615	nm
	Typical	λd typ	621
	Maximum	λd max	627
Temperature Coefficient of Voltage		∂Vf/∂T	-2.0	mV/°C
Temperature Coefficient of Radiometric Flux		∂mW/∂T	-0.8	%/°C
Temperature Coefficient of Wavelength		∂WLD/∂T	0.07	nm/°C
Electrical Thermal Resistance (Junction to Solder Point)1		Rth JS elec	4.3	°C/W

Absolute Maximum Ratings1, 2

Parameter		Symbol	Values	Unit
Forward Current (CW)3	Minimum	If pulse min	0.1	A
Forward Current (CW)3	Maximum	If pulse max	1.5	A
Reverse Voltage		V r	5	V
Power Dissipation		PD	5	W
Junction Temperature		T j	115	°C
Storage Temperature Range		T stg	-40 to 100	°C
ESD withstand Voltage ANSI/ESDA/JEDEC JS-001 (HBM, Class)		VESD	6	kV
