GW QSSPA1.EM
High-power LED with high performance, superior robustness and long lifetime.
Description
OSCONIQ® P 3030 GW QSSPA1.EM
High-power LED with high performance, superior robustness and long lifetime.
Applications
- Agriculture & Horticulture
- Entertainment
- Indoor Lighting
- Outdoor & Industrial Lighting
Features
- Package: New SMD epoxy package with silicone lens
- Typ. Radiation: 120° (Lambertian emitter)
- Color temperature: 2200K - 5000K
- CRI: 80 (min.), 83 (typ.), R9: 0 (min.)
- ESD: 8 kV acc. to ANSI/ESDA/JEDEC JS-001 (HBM, Class 3B)
- Luminous Flux: typ. 133 lm @ 3000 K, 85 °C
- Luminous efficacy: typ. 133 lm/W @ 3000 K, 85 °C
| Emission Color | White | CRI | 80 |
| Power | 1.0 W (High) | Beam Angle | ∢ Typical 120° |
| Dimensions | l Typical 3.0 mm w Typical 3.0 mm h Typical 0.75 mm |
Brightness | Typical ΦV: 134 lm Typical IV: 40.7 cd Typical ΦE: 417 mW Typical IE: 127 mW/sr |
| Operating Temperature | Top Minimum -40°C/Top Maximum 125°C |
| Product Category | Description | Order Code |
|---|---|---|
| GW QSSPA1.EM-KYLD-XX510-1 | ΦV = 104.0 ... 130.0 lm, 2200 K (IF = 350 mA) | Q65112A9132 |
| GW QSSPA1.EM-LALF-XX59-1 | ΦV = 112.0 ... 140.0 lm, 2500 K (IF = 350 mA) | Q65112A9205 |
| GW QSSPA1.EM-LBLH-XX58-1 | ΦV = 116.0 ... 150.0 lm, 2700 K (IF = 350 mA) | Q65112A8098 |
| GW QSSPA1.EM-LCLH-XX57-1 | ΦV = 121.0 ... 150.0 lm, 3000 K (IF = 350 mA) | Q65112A7966 |
| GW QSSPA1.EM-LELK-XX56-1 | ΦV = 130.0 ... 164.0 lm, 3500 K (IF = 350 mA) | Q65112A8252 |
| GW QSSPA1.EM-LFLK-XX53-1 | ΦV = 135.0 ... 164.0 lm, 5000 K (IF = 350 mA) | Q65112A7954 |
| GW QSSPA1.EM-LFLK-XX54-1 | ΦV = 135.0 ... 164.0 lm, 4500 K (IF = 350 mA) | Q65112A8255 |
| GW QSSPA1.EM-LFLK-XX55-1 | ΦV = 135.0 ... 164.0 lm, 4000 K (IF = 350 mA) | Q65112A8256 |
