2201-1501

5-conductor through terminal block; with push-button

Send Inquiry

Download

Description

5-conductor through terminal block; with push-button; 1.5 mm²; with test port; suitable for Ex e II applications; side and center marking; for DIN-rail 35 x 15 and 35 x 7.5; Push-in CAGE CLAMP®; 1,50 mm²; gray

2201 Series Feed-Through Terminal Block with Push-in CAGE CLAMP®

This feed-through terminal block (item number 2201-1501) is designed for simple and secure connections. A stripping length of 9 to 11 mm is required for the conductor connection. Whether in industrial or building applications, these feed-through terminal blocks allow electrical conductors to be connected quickly and securely. Depending on the design, they are suitable for traditional through-wiring or potential distribution. This product features Push-in CAGE CLAMP® technology. Push-in CAGE CLAMP® is the maintenance-free universal connection for all conductor types with the added benefit of direct push-in connection. Rigid conductors and stranded conductors with ferrules can be connected directly without tools. Pretreatment of the conductors, such as crimping on ferrules, is not required. The dimensions are width x height x depth (4.2 x 80.6 x 39.5) mm. This feed-through terminal block is suitable for conductor cross-sections from 0.25 mm² to 2.5 mm², depending on the conductor type. This feed-through terminal block is operated by a push-button. TOPJOB® S terminal blocks ensure a secure electrical connection in various industrial applications and in modern building installations. With just one terminal block system, you can work anywhere in the world and in any application. This product is suitable for certain Ex applications (see product data sheet).

Ex information

Reference hazardous areas	See "Downloads – Documentation – Additional Information: Technical Section; Technical Explications"
Ratings per	ATEX: PTB 05 ATEX 1094 U / IECEx: PTB 05.0034U (Ex eb IIC Gb)
Rated voltage EN (Ex e II)	550V
Rated current (Ex e II)	17A
Rated current (Ex e II) with jumper	16A

Power Loss

Power loss, per pole (potential)	0,56W
Rated current I_N for specified power loss	17,5A

Connection data

Clamping units	5
Total number of potentials	1
Number of levels	1
Number of jumper slots	2

Connection 1

Connection technology	Push-in CAGE CLAMP^®
Actuation type	Push-button
Connectable conductor materials	Copper
Nominal cross-section	1.5 mm²
Solid conductor	0.25 … 2.5 mm² / 22 … 14 AWG
Solid conductor; push-in termination	0.75 … 2.5 mm² / 18 … 14 AWG
Fine-stranded conductor	0.25 … 2.5 mm² / 22 … 14 AWG
Fine-stranded conductor; with insulated ferrule	0.25 … 1.5 mm² / 22 … 16 AWG
Fine-stranded conductor; with ferrule; push-in termination	0.75 … 1.5 mm² / 18 … 16 AWG
Note (conductor cross-section)	Depending on the conductor characteristic, a conductor with a smaller cross-section can also be inserted via push-in termination.
Strip length	9 … 11 mm / 0.35 … 0.43 inches
Wiring direction	Front-entry wiring

Physical data

Width	4.2 mm / 0.165 inches
Height	80.6 mm / 3.173 inches
Depth from upper-edge of DIN-rail	32.9 mm / 1.295 inches
Depth	39.5 mm / 1.555 inches

Mechanical data

Mounting type	DIN-35 rail
Marking level	Center/side marking

Material data

Note (material data)	Information on material specifications can be found here
Color	gray
Material group	I
Insulation material (main housing)	Polyamide (PA66)
Flammability class per UL94	V0
Fire load	0,185MJ
Weight of insulation material	4,82g
Weight	7,2g
