Description
Dong Feng series delivers unique brilliant light with outstanding efficiency and elegant design. Professional chip bonding process is applied which contributes extremely low thermal resistance performance. It also provides distinct and uniform light pattern by adopting one piece phosphor sheet. And automotive grade material and strict quality control during the whole process flow make it highly robust and stable to withstand extreme environment conditions and wide range of temperature change. With Dong Feng series, you will start to experience and enjoy the excellent adventure during driving time.
Features
• Package: Aluminum Nitride Ceramic
• Excellent Brightness: 250 lm @1A
• With an Electrically Isolated Thermal Pad Structure
• Automotive Grade Material but Cost Effective
• Color: According to ECE
• Superior Reliability Performance and Lifetime
• Easy to Design Your Own Type of Array
• Pin to Pin and Compatible to Leading Brand
Applications
• Exterior Automotive Lighting
• Turn Signal
• Warning Light
| Order Code | Power(W) | Dimension(mm) | Typ.Flux(lm) | CRI(Ra) | Color-CCT(K) | Color | LES(mm) | Typ.IF(mA) | Typ.VF(V) | View Angle(Deg.) | Max.IF(mA) |
| 2DF105CW81F11011 | 5 | 2.00*1.60*0.79 | 430 | 65 | 6000 | Cool White | 1.15*1.15 | 1000 | 3.2 | 120 | 1500 |
| 2DF105AX81F11011 | 5 | 2.00*1.60*0.79 | 280 | 42 | 1800 | PC Amber | 1.15*1.15 | 1000 | 3.2 | 120 | 1500 |
| 2DF105GD81F11011 | 5 | 2.00*1.60*0.79 | 420 | 58 | 3000 | Golden | 1.15*1.15 | 1000 | 3.2 | 120 | 1500 |
